Τριφασικό Υβριδικό Inverter 20KW 30000W 423038
Νέο!
The ELMARK ELM3TH low voltage Series storage Inverters are designed to increase energy independence for homeowners and commercial users.
They are compatible with high voltage (150-800V) batteries.
Energy management is based on time-of-use and demand charge rate structures, significantly reduce the amount of energy purchased from the public grid.
They are compatible with high voltage (150-800V) batteries.
Energy management is based on time-of-use and demand charge rate structures, significantly reduce the amount of energy purchased from the public grid.
Thanks for the UPS function (switch time < 10ms), enables the crucial loads power on during outages.
Additionally, under the backup operation mode, the inverter provides you up to 150% peak output overloading.
ELM3TH is inverter integrated with Arc Fault Circuit Interrupter (AFCI) and rapid shutdown.
ELM3TH is inverter integrated with Arc Fault Circuit Interrupter (AFCI) and rapid shutdown.
Check the system status anytime and anywhere via online portal or smart HOME APP.
Advantages
- UPS function
- Support generator and wind turbine
- Ability to operate up to 6 inverters in parallel and increase system power up to 120kW
- Support unbalance load
- Anti-flow: Ant-feed function
- PV oversize: Max. 1.5 time PV oversize capacity
- Multiple intelligent protection
- Smart: Smart monitoring & remote firmware upgrade
- PV Reverse polarity protection
- Over current/ voltage protection
- Anti-islanding protection
- AC short circuit protection
- Residual current detection
- Ground fault monitoring
- Insulation resister detection
- PV arc detection
Technical data
- Number of poles: 3P/N/PE
- Rated power: 20KW
- Maximum power of solar panels: 30KW
- MPPT operating voltage range: 150-850V DC
- Maximum input voltage: 1000VDC
- Number of independent outputs (MPP Trackers) / Strings on each output: 2/4
- Battery voltage: 150-800VDC
- Battery Type: Lithium/Lead Acid
- Charging current: 50А
- EU performance: > 97,8%
- Display: LCD
- Modbus: RS485
- IP code: IP65
- Altitude: up to 4000m
- Ambient temperature: from -25 to 60°С
- Relative humidity: from 0 to 100%
- Weight: 28kg
- Dimension (WxHxD): 588x426x250mm
Certification
- INTERTEK/ VDE/ EN/ CE
